Gear oil pump PGH Series PGH2-2X/008RR07VU2

🛠️ Product Description

✅ The quality Gear oil pump PGH Series  PGH2-2X/008RR07VU2   is engineered by Hengmeisi – a leading China manufacturer and factory direct supplier. This Rexroth-compatible pump delivers steady performance with 8 cm³/rev displacement, designed for continuous operation in compact hydraulic circuits.

🔧 Our Gear oil pump PGH Series  PGH2-2X/008RR07VU2 features advanced pressure-compensation technology, minimal internal leakage, and quiet operation. It is fully interchangeable with the Rexroth version, offering drop-in replacement without system modifications.

⚙️ Unlike conventional gear pumps, the Gear oil pump PGH Series  PGH2-2X/008RR07VU2 uses precision gear machining to reduce wear and extend service life. It works reliably across a wide range of speeds and fluid viscosities, even in demanding industrial environments.

🛡️ The Gear oil pump PGH Series  PGH2-2X/008RR07VU2 is built with high-strength cast iron housing and premium FKM seals, ensuring excellent leak resistance and compatibility with various hydraulic oils.

📦 Available as both Hengmeisi’s interchangeable version and original Rexroth units, the Gear oil pump PGH Series  PGH2-2X/008RR07VU2 meets diverse customer needs with cost-effective and authentic options.

✨ Product Advantages

🔄 Rexroth-Equivalent Full Compatibility

The Gear oil pump PGH Series PGH2-2X/008RR07VU2 matches the original Rexroth model in dimensions, performance and mounting, enabling seamless plug-and-play replacement.

📈 High Efficiency & Energy Saving

Rated for continuous high pressure, this pump maintains excellent volumetric efficiency, reducing energy consumption and supporting eco-friendly hydraulic system design.

🔇 Low Noise & Smooth Operation

Optimized gear tooth profile minimizes flow pulsation and noise, making the Gear oil pump PGH Series PGH2-2X/008RR07VU2 suitable for precision machinery and noise-sensitive applications.

💪 Durable Industrial Construction

Robust cast iron body and high-performance seals withstand harsh operating conditions, ensuring long service life and low maintenance requirements.

🔗 Flexible System Integration

The compact design supports multi-pump combinations and standard ISO mounting, making the Gear oil pump PGH Series PGH2-2X/008RR07VU2 easy to integrate into various system configurations.

📋 Model Code Explanation

The Gear oil pump PGH Series PGH2-2X/008RR07VU2 features an intuitive coding system for quick parameter identification:

PGH2: Frame size 2 internal gear pump series

2X: Second-generation optimized structural design

008: Nominal displacement of 8 cm³/rev

RR: Rotation direction and shaft configuration (clockwise, cylindrical shaft end)

07VU2: Standard sealing and mounting specifications, ISO-compliant

🔩 Product Structure

Core Architecture: Precision Internal Gear Mechanism

Composed of high-precision internal gear, pinion shaft, and pressure-compensation elements for consistent flow and pressure output.

Axial & Radial Gap Compensation System

Self-adjusting compensation maintains optimal seal gaps, preserving efficiency even as components wear over time.

Premium Material Construction

High-strength cast iron housing provides structural rigidity; hardened gear surfaces ensure long-term wear resistance.

Integrated Mounting & Sealing Design

ISO-standard flange and shaft configuration ensures compatibility with common motor interfaces; multi-stage sealing prevents contamination ingress.

🚜 Application Scenarios

Small hydraulic power units and CNC machine tools

Light-duty injection molding and stamping equipment

Auxiliary hydraulic systems for construction machinery

Packaging, textile and printing machinery

Material handling and logistics equipment

Mobile hydraulic systems for light-duty vehicles
