Gear oil pump AZPF Series AZPF-12-016RCB01MB

⚙️ Product Description

Hengmeisi provides reliable products that meet Rexroth standards. The Gear oil pump AZPF Series AZPF-12-016RCB01MB gear pump – precision-machined with optimized gearing – ensures stable flow, low pulsation, extended durability, and strong anti-pollution performance for diverse hydraulic systems.

✨ Product Advantages

🔹 Unique External Gear Pump Structure Design

Totally different from vane pumps & plunger pumps, AZPF-12-016RCB01MB adopts high-precision involute gear meshing structure. It cancels complex variable displacement mechanisms, greatly simplifies internal structure, realizes ultra-stable pressure output, low failure rate and extremely convenient daily maintenance.

🔹 Integrated Stable Hydraulic Pressure Control

Built-in optimized pressure stabilization hydraulic circuit, the pump achieves stepless stable displacement adjustment, maintains constant output pressure under severe working conditions, effectively avoids sudden pressure surge & pressure loss, ensures stable operation of the whole hydraulic system.

🔹 Premium Heavy-Duty Durable Materials

Pump housing adopts high-strength lightweight aluminum alloy; gear parts use high-hardness quenched & ground alloy steel. Imported high-temperature resistant seal fittings adapt -30℃ to +120℃ extreme working environment, bear long-time high-load operation at rated speed, and extend overall pump service life sharply.

🔹 Built-In Excellent Anti-Contamination Performance

Equipped with multi-layer internal anti-impurity protection structure & optimized oil passage design, it effectively resists fine oil impurities. It keeps stable efficiency under bad hydraulic oil quality conditions, greatly reduces internal wear, and ensures reliable long-term continuous operation.

🔢 Model Code Meaning

AZPF-12-016RCB01MB has clear & unified coding logic, easy for customers to judge product parameters:

AZPF: Standard external meshing hydraulic gear pump series

12: Pump frame size & installation series specification

016: Rated displacement 16cm³/rev, matching medium-large flow hydraulic systems

R: Oil port direction & shaft rotation specification

C: High temperature resistant seal material grade

B: Flat key drive shaft structure

01: Flange installation size standard

MB: Fixed assembly & sealing configuration standard

As core model of AZPF series, AZPF-12-016RCB01MB owns outstanding compression resistance & efficiency performance, widely recognized and purchased by global hydraulic machinery buyers.

🏗️ Product Structure

1.🧩 Core Architecture: High-Precision External Gear Pump Structure

AZPF-12-016RCB01MB consists of precision gear pair, heavy-duty sliding bearing, sealed aluminum pump body, fixed flange and integrated oil passage assembly, completely different from variable vane & plunger pump internal structure.

2. ⚡ Working Mechanism: Stable Gear Meshing Transmission

Rely on synchronous meshing rotation of driving & driven gears to complete oil suction and pressurized oil discharge. Realize closed-loop stable flow output, no instantaneous flow impact, keep whole hydraulic system running smoothly.

3. 🛡️ High-Grade Matching Materials

High-hardness wear-resistant alloy gear, corrosion-resistant lightweight pump shell, low-temperature & high-temperature resistant full-series seals, all parts pass strict precision tolerance control.

4. 🛡️ Integrated Operation Protection Function

Built-in pressure buffering & anti-backflow structure, effectively protect pump body from hydraulic impact damage, improve overall operation safety and service durability.

🚜 Application Scenarios

🏭 Large CNC machine tools, precision molding equipment, industrial hydraulic station systems

🏗️ Construction machinery, small excavators, loading machinery, engineering auxiliary hydraulic units

🚜 Agricultural machinery, farm lifting equipment, agricultural vehicle hydraulic power systems

✈️ Aerospace supporting hydraulic fixtures, special heavy-load industrial supporting equipment

🚢 Marine auxiliary hydraulic systems, mobile hydraulic power units, all kinds of low-noise high-pressure hydraulic occasions
