Gear oil pump AZPF Series AZPFF-10-011/005RSA2020MB

⚙️ Product Description

The premium Gear oil pump AZPF Series AZPFF-10-011/005RSA2020MB tandem gear pump is engineered by Hengmeisi – a leading China manufacturer and factory direct supplier. This dual-section pump features two integrated gear stages (11 + 5 cm³/rev), delivers reliable flow distribution, and ensures consistent performance in space-limited hydraulic applications。

✨ Product Advantages

🔹 Tandem Dual Gear Pump Structure Design

Unlike single gear pumps or plunger pumps, the AZPFF-10-011/005RSA2020MB combines two independent gear stages in one compact housing. It eliminates the need for multiple separate pumps, saving installation space while providing simultaneous flow to two different hydraulic circuits.

🔹 High-Precision Gear Meshing for Low Noise

Precision-machined gear pairs reduce flow pulsation and vibration, resulting in quiet operation. The optimized tooth profile minimizes pressure ripples, making it suitable for noise-sensitive industrial environments and mobile machinery.

🔹 Premium Materials for Durability

★ Housing: High-strength lightweight aluminum alloy, corrosion-resistant

★ Gears: Hardened alloy steel with precision grinding for wear resistance

★ Seals: High-performance materials compatible with -30°C to +120°C, leak-free at full pressure

🔹 Integrated Pressure & Flow Stability

Each pump stage operates independently, maintaining stable flow even under varying load conditions. The integrated design ensures synchronized performance, reducing system complexity and improving overall reliability.

🔢 Model Code Explanation

The model code AZPFF-10-011/005RSA2020MB has a clear, intuitive structure:

※ AZPFF: Tandem external gear pump series (dual-section design)

※ 10: Series designation, indicating compact frame size

※ 011/005: Rated displacements (11 cm³/rev + 5 cm³/rev) for two pump stages

※ R: Rotation direction (right-hand)

※ S: Shaft design (spline/flat key variant)

※ A: Seal material and temperature rating

※ 2020: Pressure rating and bearing configuration for both stages

※ MB: Mounting flange specification (standard industrial compatibility)

This model is optimized for multi-circuit systems, making it widely favored by global purchasers in material handling, construction, and industrial automation.

🏗️ Product Structure

1. 🧩 Core Architecture: Tandem Dual Gear Pump Structure

The AZPFF-10-011/005RSA2020MB consists of two independent gear pump sections housed in a single compact aluminum body, eliminating the need for multiple pump installations.

2. ⚡ Working Mechanism: Dual-Stage Flow Distribution

Each gear stage operates independently to draw fluid from the inlet and deliver it to separate outlets. This design allows simultaneous powering of two different hydraulic functions with different flow requirements.

3.🛡️ Material Upgrades

☀ Gear Pairs: Hardened alloy steel with precision grinding for low wear

☀ Housing: Lightweight, corrosion-resistant aluminum alloy

☀ Seals: High-temperature resistant components for leak-free operation

4. 🛡️ Integrated Reliability Features

Built-in pressure relief options and robust bearing design prevent premature wear, ensuring long-term reliability in continuous-duty industrial applications.

🚜 Application Scenarios

🏭 Industrial hydraulic systems: CNC machine tools, multi-circuit hydraulic power units

🏗️ Construction machinery: Compact excavators, skid-steer loaders, and cranes

🚜 Agricultural machinery: Tractors, harvesters, and farm equipment hydraulics

📦 Material handling: Forklifts, pallet trucks, and lifting platforms

🚢 Marine hydraulics: Auxiliary systems for small vessels and workboats
